Security Control Panels

¥47.00

Alarm Control Panels DSM-140

Enclosure Design
Color: Frost White
Indicators: 3 zone LEDS, 2 status LEDs
Dimensions (HxWxD):
Environmental Considerations
Relative Humidity: 0% to 85% noncondensing
Temperature (Operating): 20°C to +50°C
Outputs
Alarm Relay: Form “C”,contacts rated at 3 A @ 28 VDC or 120 VAC
Solid-State: Two DC current sinks; 250 mA maximum per output at 0.1 VDC saturation.
Power Requirements
Current Draw: 30 mA standby, 70 mA alarm
Voltage (Input): 10.2 VDC to 15 VDC
Zone Characteristics
EOL Resistors: 10 kΩ
Response Time: 500 ms

Security Control Panels DSM-140

3 zones and a separate key-switch input
3 user codes and an unlock door code
Quick Arm function
Built-in piezo buzzer
Built-in tamper switch
Keys back-lit by LEDs

The mini panel has three alarm input zones,one alarm relay output,two solid-state outputs,key switch input,instant input and supports three user PIN codes including the master code and one door unlock PIN code.

security alarm control panels

security control panels
security control panels

Home security systems are networks of integrated electronic devices working together with a central control panel to protect against burglars and other potential home intruders.

A basic home security system includes:

A control panel or base station with a separate keypad
Door and window sensors
Motion sensors
Glass break sensors
Outdoor Siren & Indoor siren
Security cameras
But there are plenty of other devices available to enhance your home’s security, including smart home products and environmental sensors.

Additional information

Weight 41 kg
Dimensions 23 × 55 × 34 cm
